Regular LED Strip

  • 3528 LED Strip 60leds
  • 3528 LED Strip 60leds
  • 3528 LED Strip 60leds
  • 3528 LED Strip 60leds
  • 3528 LED Strip 60leds
3528 LED Strip 60leds3528 LED Strip 60leds3528 LED Strip 60leds3528 LED Strip 60leds3528 LED Strip 60leds

3528 LED Strip 60leds

Product Parameter:

P/N

Size/mm

LED/Qty/m

Brand

Luminance/LED

Angle

Voltage

Wattage/M

IP Rate

MDR-3528-100-60X

5000*8

3528/60pcs

Epistar

7-8LM

140

DC12V

4.8W

IP20/68


Features :
-This flexible LED strip soldered 60pcs SMD 3528 LED .
-Flexible PCB: White , PCB Width 8mm.Cutable each set of 6 LED
-Waterproof version (Silicon Tube coating : W12*H4mm. )
-DC 12V constant voltage operation
-Voltage drop from start to end of 5 M ± 2V.
- Each end soldered a 3 Pin bare wire 22AWG at 15cm length
-customizable of length


Application:
1. Hotels,restaurants,Under cabinet lighting.
2. Shopping malls,various shops.
3. Coffee/wine bars, furniture light.
4. Cinemas, beauty centers .
